Model | ZN1035U5K5 | ZN1035U5K5A | ZN1035UCK5 | ZN1035UCK5A |
Model Specification | standard | luxury | flagship | luxury | standard | luxury | flagship | luxury |
Drive Type | 2WD | 4WD |
Transmisson | 5MT | 7AT | 6MT | 7AT |
Body Parameter | L×W×H(mm) | 5263×1850×1790 | 5263×1850×1808 |
Wheelbase(mm) | 3150 |
Track(front/rear)(mm) | 1570/1570 |
Cargo L×W×H(mm) | 1510×1562×475 |
Minimum Ground clearance(mm) | 205 | 218 |
Approach Angle/Departure Angle(°) | 30°/25° | 31°/26° |
Minimum Turning Radius(m) | 6.25 |
G.V.W(kg) | 2630 |
Curb Weight(kg) | 1669 | 1696 | 1781 | 1791 |
Load Capacity(kg) | 636 | 609 | 524 | 514 |
Fuel Tank(L) | 73 |
Maximum Speed(km/h) | 160 | 165 | 160 | 165 |
Engine | Engine Type | QR25 |
Fuel Type | Gasoline |
Emission Standard | China V+OBD |
Displacement(L) | 2.5 |
Rated Power(Kw) | 135 |
Maximum Torque(N·m) | 236 | 251 |
Running System | Suspension(front/rear) | Double-wishbone,independent/Steel spring |
Brakes | Disc/Drum |
255/70R16 | ● | ● | ● | ● | ● | ● | ● | ● |
Steel Wheel | ● | - | - | - | ● | - | - | - |
Aluminum Wheel | ○ | ● | ● | ● | ○ | ● | ● | ● |
Comfort | Height Adjustable Steering Wheel | ● | ● | ● | ● | ● | ● | ● | ● |
Single Zone Manual Air Conditioning (pollen filtration) | ● | - | - | - | ● | - | - | - |
Double Zone Automatic Air Conditioning, (pollen filtration) | - | ● | ● | ● | - | ● | ● | ● |
Air Outlet In The Second Row | - | ● | ● | ● | - | ● | ● | ● |
6 Direction Manual Adjustment On Driver Side(cloth seat) | ● | ● | - | ● | ● | ● | - | ● |
8 Direction Electic Adjustment On Driver Side(leather seat) | - | - | ● | - | - | - | ● | ○ |
Central Dashboard | Black | ● | - | - | - | ● | - | - | - |
Piano Paint | - | ● | ● | ● | - | ● | ● | ● |
Interior Door Handle | Black | ● | - | - | - | ● | - | - | - |
Chroming | - | ● | ● | ● | - | ● | ● | ● |
Central Lock | ● | ● | ● | ● | ● | ● | ● | ● |
Remote Key | - | ● | ● | ● | - | ● | ● | ● |
12V Power Supply(2) | ● | ● | ● | ● | ● | ● | ● | ● |
Glasses Case | - | ● | ● | ● | - | ● | ● | ● |
Map Lamp(3 Usual Lamp)+Room Lamp | ● | - | - | - | ● | - | - | - |
Map Lamp(2 Usual Lamp+Atmosphere Lamp)+Room Lamp | - | ● | ● | ● | - | ● | ● | ● |
Cup Stand | 2 In Center Console | ● | - | - | - | ● | - | - | - |
2 In Center Console+2 In Instrument Desk | - | ● | ● | ● | - | ● | ● | ● |
Rear Window Defroster | - | ● | ● | ● | - | ● | ● | ● |
Power Window In The Driver Side (anti-pinch) | ● | ● | ● | ● | ● | ● | ● | ● |
Power Windows(4 Doors) | ● | ● | ● | ● | ● | ● | ● | ● |
Exterior | An Electromagnetic Filler Cap | ● | ● | ● | ● | ● | ● | ● | ● |
Exterior Door Handle/Trunk Door Handle | Black | ● | - | - | - | ● | - | - | - |
Chroming | - | ● | ● | ● | - | ● | ● | ● |
Front Air Grille | Silvering | ● | - | - | - | ● | - | - | - |
Chroming | - | ● | ● | ● | - | ● | ● | ● |
Safety | Double Airbag | ● | ● | ● | ● | ● | ● | ● | ● |
Engine Anti-theft | - | ● | ● | ● | - | ● | ● | ● |
ABS+EBD+BA | ● | ● | ● | ● | ● | ● | ● | ● |
Black Manual Rear Mirror+Electric Adjust | ● | - | - | - | ● | - | - | - |
Chroming Manual Rear Mirror+Electric Adjust | - | ● | - | ● | - | ● | - | ● |
Chroming Manual Rear Mirror+Electric Adjust+Turn Light | - | - | ● | - | - | - | ● | - |
Anti-glare Interior Rearview Mirror | ● | ● | ● | ● | ● | ● | ● | ● |
Halogen Headlights (height adjustable) | ● | ● | - | ● | ● | ● | - | - |
LED Headlights (height adjustable) | - | - | ● | - | - | - | ● | ● |
Front Fog Lamp | - | ● | ● | ● | - | ● | ● | ● |
Rear Fog Lamp | ● | ● | ● | ● | ● | ● | ● | ● |
Daytime Runing light | - | - | ● | - | - | - | ● | ● |
The Front Seat Belts(three point + preload + high adjustable) | ● | ● | ● | ● | ● | ● | ● | ● |
The Second Row Seat Belts(two sides/3 point+middle/2 point) | ● | ● | ● | ● | ● | ● | ● | ● |
Child Safety lock | ● | ● | ● | ● | ● | ● | ● | ● |
The Internal Rope Hook | ● | ● | ● | ● | ● | ● | ● | ● |
A/V system | 2Loudspeaker System | ● | ● | - | ● | ● | ● | - | ● |
6Loudspeaker System | - | - | ● | - | - | - | ● | - |
Double DIN Acoustics(AM+FM+AUX +USB) | ● | ● | ● | ● | ● | ● | ● | ● |
Others | Bed liner(coating) | ○ | ○ | ○ | ○ | ○ | ○ | ○ | ○ |
Side Pedals + Anti-Roll Stand | - | ○ | ○ | ○ | - | ○ | ○ | ○ |
7 Inch Display + Navigation + Reverse Image | - | ○ | ○ | ○ | - | ○ | ○ | ○ |
Driver Side 8 Direction Electic Adjustment+Leather Suite(seat、gear lever、hand brake、steering wheel、door trim、the central store box) | - | - | ● | - | - | - | ● | ○ |
